Features:
- All Diffused Structure
- High Surge rating
- Soft Reverse Recovery
- Rugged Ceramic Hermetic Package
- Pressure Assembled Device
PRODUCT VISUAL01 / GALLERY
POWER COMPONENT
YZPST-M2639ZC450
✓Technical product information✓Application-focused selection support✓Catalog and requirement-based inquiry
Emailinfo@yzpst.net
Phone+86 138 0527 8321
Tip: include the part number, target voltage/current and application environment.
DOCUMENT CENTER
Downloads & technical files
http://www.youtube.com/channel/UCZ3mV8GmGNcX4WcYEoWX-_g/featured
For guaranteed maximum values, contact factory
Mounting surfaces smooth, flat and greased
Typical Applications:
- Rectifier for Drives Applications
- Medium voltage converters
- Pulsed power applications
- Crowbar Applications
Electrical Characteristics And Ratings
VRRM (1) | VRSM (1) |
4200 | 4200 |
VRRM = Repetitive peak reverse voltage
VRSM = Non repetitive peak reverse voltage
VRSM = Non repetitive peak reverse voltage
Repetitive peak reverse leakage | IRRM |
20 mA
150 mA
|
Conducting - on state
Parameter | Symbol | Min | Max. | Typ | Units | Conditions |
Max. Average value of on-state current | IF(AV)M | 2639 | A | Sinewave,180oconduction,Tc=55oC | ||
RMS value of on-state current | IFRMS | 4922 | A | Nominal value | ||
Peak one cycle surge
(non repetitive) current
| IFSM | 27.5 | kA | Tj=150°C, VR=0,8VRRM, tp=10ms | ||
I square t | I2t | 3.79x103 | kA2s | 10 msec | ||
Peak on-state voltage | VFM | 2.25 | V | IFM =3000 A; Tj = 150 oC | ||
Threshold voltage | VFO | 1.38 | Tj = 150 oC | |||
Forward slope resistance | rF | 0.29 | mΩ | Tj = 150 oC | ||
Reverse Recovery Current (4) | IRM(REC) | - | 280 | A |
IFM = 1000 A; dIF/dt = 60 A/ms,
Tj = 150 oC
| |
Reverse Recovery Charge (4) | Qrr | - | 2300 | mC | ||
Reverse Recovery Time (4) | tRR | - | 8.5 | ms |
Thermal And Mechanical Characteristics
Parameter | Min. | Max. | Typ. | Units | Conditions | |
Operating temperature | Tj | -40 | +150 | oC | ||
Storage temperature | Tstg | -40 | +150 | oC | ||
Thermal resistance - junction to case | RQ (j-c) | 0.011 | K/W |
Double sided cooled
Single sided cooled
| ||
Thermal resistance - case to sink | RQ (c-s) | 0,.022 | K/W |
Double sided cooled
Single sided cooled
| ||
Mounting force | P | 37 | 47 | - | kN | |
Weight | W | 1700 | g | About |
Case Outline And Dimensions
Sym | A | B | C | D | H |
mm | 109 | 73 | 98 | 3.5×3 | 36±1 |
YZPST can provide Following Equivalent List of Fast/Inverter Diodes
FAST/INVERTER DIODES | ||||
TYPE | Equivalent | IAV | PIV | DIA/HT |
A696L | 9110/SM18CXC724/M1022LC180 | 1000A | 1800V | 34/27 |
3178 | SM18CXC924/M149NC180 | 1496A | 1800V | 47/27 |
M1494 | SW25CXC924 | 1494A | 2500V | 47/27 |
ZWDQ8 | L5646/ZWDQ 815645 fast recovery stud diode | |||
YZPST can provide Following Equivalent List of Fast Recovery Diodes (Capsule Types)
| Type | IF(AV ) | VRRM | IFSM @TVJ M &1 0ms | IRRM (max) Tj=125 °C | VFM(max) | Trr (max) | Tvj | Rthjc | F±10 % | |
| IFM (A) | V | µs | °C | K/W | KN | |||||
| A | V | KA | mA | |||||||
| A337 | 650 | 500-1500 | 10 | 40 | 2000 | 1.9 | 4.0 | 125 | 0.045 | 3.6 |
| A596 | 750 | 700-1600 | 13 | 50 | 3500 | 2.3 | 4.0 | 150 | 0.06 | 9.8 |
| A696 | 1000 | 2000-2600 | 14 | 100 | 100 | 1.9 | 5.0 | 150 | 0.04 | 15 |
| A796 | 925 | 1500-2500 | 13.8 | 75 | 1000 | 1.75 | 3.5 | 125 | 0.02 | 25 |
For more information about Fast Recovery Diode please download the PDF file above named "YANGZHOU POSITIONING TECH CO Power thyristor and diode parts "
