YZPST-SQL100A-1600V

RATING

SQL

SQL

SQL

SQL

SQL

SQL

SQL

Symbol

UNIT

100A-02

100A-04

100A-06

100A-08

100A-10

100A-12

100A-16

VRRM

200

400

600

800

1000

1200

1600

V

Maximum reecurrent peak reverse voltage

 Maximum rms lnput voltage

VRMS

140

280

420

560

700

840

1120

V

 Maximum dc blocking voltage

VDC

200

400

600

800

1000

1200

1600

V

Tc=55℃

ID

100

A

Maximum average forward output rectifled

Peak forward surge current 8.3ms single half sine-wave

IFSM

1000

A

IF  =33A

VF

1.1

V

Maximum forward voltage

Ta =25℃ Ta =100℃

IR

10

μA

Maximum reverse voltage

IR(H)

200

μA

Thermal resistance junction to shell

RθJC

0.3

°C/W

Thermal resistance shell to environment

RθJA

0.5

°C

Operating temperature range

TJ

-40～+125

°C

storage temperature range

TSTG

-40～+150

°C
