YZPST-STD60-45

Name: YZPST-STD60-45
Brand: YZPST

✓Technical product information✓Application-focused selection support✓Catalog and requirement-based inquiry

Emailinfo@yzpst.net

Phone+86 138 0527 8321

REQUEST A TECHNICAL QUOTE ↗

Tip: include the part number, target voltage/current and application environment.

DOCUMENT CENTER

Downloads & technical files

YZPST-STD60-45-Schottky Power Diode In DO-5 Stud Package.pdfDOWNLOAD ↘YANGZHOU POSITIONING TECH CO Power thyristor and diode parts 20200518.pdfDOWNLOAD ↘

http://www.youtube.com/channel/UCZ3mV8GmGNcX4WcYEoWX-_g/featured

Features

• Fast Switching
• Low forward voltage drop VF
• Guard ring protection
• High surge capacity
• High efficiency low power loss

Electrical Ratings (TC = 250 C unless otherwise noted)

Parameter	Symbol	Values Units
Repetitive peak reverse voltage	VRRM	45	V
DC blocking voltage	VDC	45	V
Non-repetitive peak reverse voltage	VRSM	54	V
Average rectified forward current (TC = 850C)	IF(AV)	60	A
Non-repetitive peak surge current (surge applied at rated load conditions halfwave single phase 50 Hz)	IFSM	600	A







Maximum Ratings (TC 250 Cunless otherwise noted)
Parameter	Test Conditions	Symbol	Values	Units
Maximum instantaneous forward voltage	IF= 30 A	VF	58
	IF = 60 A		66
	IF= 120 A		89
Maximum instantaneous reverse current at rated DC voltage	0 TC = 25 C	IR	50
	0 TC = 125 C		125

Thermal& M hanl I Specnlcatlons(2:5 0Cunless otherwlse noted)
Para met@rs	mbol	Values	Unns
Maximum thermal resistancejunction to case	R \|	1.0	C!W
Operating junction tempera-e.tmure range		.65 to +150
Storage temperature	!st	.65 to +150
Mounting torque (non.lubricated threads)		15	in.lb
Approximate allowable weight	W	45 6

YZPST can provide Following List of Schottky Diodes

Schottky TO-277 high power TO-220F plastic packaging		SS110F 28mil	28
SB1045L 88 / 98MILvoltage drop is about 0.5V	88/98	SS24F 40mil	40
SB1045L 102MIL voltagedrop is about 0.43V	102	SS210F 40mil	40
SB1045L 112MIL	112	SS34F 45mil	45
10U45 Taiwan groove chip65MIL low positive	65	SS32F/SS34F50mil	50
10U45 70MIL domestic	70	SS54F 55MIL	55
SB1060 TO277	88	SS510F 60mil	60
SB10100 TO277	88	SS12	28
SB1545L TO277 118MIL	118	SS14	28
TVS series products, SMD parts		SS16	28
P4KEseries（Such asP4KE100A) within 240V	52	SS18-SS110	28
P6KEseries（Such asP6KE200A) within 240V	52	SS24Flat 35MIL	35
1.5KE OJ pickling DO27 within 240V	90	SS34Flat40/45MIL	40/45
1.5KE GPP frame DO27 within 240V	145	SS25-SS26 40MIL	40
SMAJ5.0A(CA)-SMAJ240A(CA) SMA	60	SS28-SS210	40
SMBJ5.0A(CA)-SMBJ240A(CA) SMB	60/72	SS35-SS36 40MIL	40
SMCJ5.0A(CA)-SMCJ240A(CA) SMC	90/110	SS35-SS36 45MIL	45
3KP/5KP series OJ	140	SS38-SS31050MIL	50
SOD-123FL SMD (rectifier, fast, highfrequency, ultra fast,Schottky)		S315-SS32050MIL	50
		S315-SS32050MIL	50
A1-A7	42/46	SMA frame patch (rectifier,fast, high frequency, ultrafast, Schottky)
F7	42/46	SS54 55MIL
F1-F6		SS56 55MIL
S1M 46MIL	46	SS510 55MIL	55
F1M 46MIL		SS515-SS52055MIL
E1A-E1J	42	SS54-SS56 60MIL
U1A-U1M	42	SS510 60MIL	60
1N5819W/K14	28	SS515-SS52060MIL
K2/K6	28/28	MINI Rectifier Bridge StackSchottky Bridge Stack
K110	28	DB107	50
（K24）40MIL	40	DB107S disk	50
（K26）40MIL	40	DB157	50
（K210）40MIL	40	DB157S	50
（K220）40MIL	50	MB6S 42
（K34）50MIL	50	MB8S 42	42
（K36）50MIL	50	MB10S 42
（K310）50MIL	50	MB6S 46
K54 55MIL	55	MB8S 46	46
SAMF patch (rectification, fast, highfrequency, ultra fast, Schottky)		MB10S 46
M7F 42/46MIL	42/46	MB6F 42MIL	42
RS1AF-RS1MF	40/46	MB10F 42MIL	42
US1AF-US1MF	40/46	MB6F 46MIL	46
ES1AF-ES1JF	40/46	MB10F 46MIL	46
S2MF	50/60	MB6S-MB10S50MIL
RS2AF-RS2MF	50/60	MB6F-MB10F50MIL
US2AF-US2MF	50/60	TB10S 50MIL	50
ES2AF-ES2JF	50/60	ABS6-ABS10 50MIL
S3MF	80	ABS22-ABS210 60MIL	60
SS14F 28mil	28	MB6M 46mil	46
SS16F 28mil	28	MB10M 46mil	46

For more information about Schottky diode please download the PDF file above named " YANGZHOU POSITIONING TECH CO Power thyristor and diode parts "
